ð The operation unit (1) is fixed to the support (4) by the magnetic plate (5).
Connecting the operation unit (1)
Connect the 12V power supply cable to the 3-pin socket on the tractor and machine.
Connect the supplied cable to the bushing(2) of the operation unit(1).
7.9 Connecting KRONE terminal DS 500
NOTICE
Short circuit caused by impurities and moisture in the plug connection
The machine may be damaged by a short circuit.
Make sure that the plugs and sockets are clean and dry.
