2 Safety
2.7 Safety equipment
36
Comprima F 155
Original Operating Instructions 150001049_01_en
Pos. Designation Explanation
3.1 Overload protection universal
shaft
• The overload protection guards the tractor and
the machine from load peaks, refer to
page38.
3.2 Pick-up overload protection • The overload protection guards the tractor and
the machine from load peaks, refer to
page38.
4 Wheel chocks • The wheel chocks secure the machine against
rolling away. 2wheel chocks are affixed to the
machine, refer to page77.
• For version with "Parking brake": In order to
prevent the machine from rolling away, use the
parking brake in addition to the wheel chocks,
refer to page76.
5 Support jack • The support jack is used to keep the machine
stable when it is not connected to the tractor,
refer to page73.
6 (de-
pending
on
country
version)
SMV emblem • The Slow-Moving Vehicle emblem is attached
to slow-moving machines or vehicles which
move slower than 40km/h (25mph) on public
highways, refer to page36.
• The SMV emblem is at the rear in the centre or
on the left.
• If the machine is transported on transport
vehicles (e.g. lorry or train), the SMV emblem
must be covered or removed.
7 Stop cock tailgate • The tailgate stop cock is a safety component
which prevents the tailgate from unintentionally
closing, refer to page75.
2.7.1 SMV emblem
KM000-567
The SMV emblem (Slow-Moving Vehicle) (1) is attached to slow-moving machines or vehicles
travelling on public highways at a speed of less than 40km/h (25mph).
The SMV emblem (1) is at the rear in the centre or at the rear on left.
When driving the machine on public highways, the SMV emblem must be mounted.
If the machine is transported on transport vehicles (for example lorry or train), the SMV emblem
must be covered or dismounted.
