8 Operation
8.14 Lifting/lowering the feeder rotor floor
84
Comprima F 155
Original Operating Instructions 150001049_01_en
Removing
 Remove the linch pins(3) from the right and left sides of the pick-up.
 Remove the spring(4) from the right and left sides of the pick-up.
 Push the baffle sheet(1) to one side and remove.
Mounting
 • Place the baffle sheet(1) on the crop press roller(2) and secure with the linch pins(3) on
the right and left sides of the pick-up.
 Mount the spring(4).
8.14 Lifting/lowering the feeder rotor floor
For version with "Drop floor of feed rotor"
In case of crop blockage, the feeder rotor floor can be lifted.
 To preselect the feeder rotor floor, press key
on the terminal.
 To lift the feeder rotor floor, actuate the control unit (yellow, 3+).
 To lower the feeder rotor floor, actuate the control unit (yellow, 3+).
8.15 Net wrapping
For version with "Net wrapping"
8.15.1 Inserting the net roll
To ensure that the sleeve clamp can hook completely into the sleeve of the net roll, a cardboard
sleeve should be used. If a plastic sleeve with grooves is used, the sleeve clamp may hook into
the grooves, transferring the brake force from the brake disc to the net roll. For this reason,
plastic sleeves without grooves are not recommended.
When using cardboard sleeves, make sure they are inserted in the correct position. Moisture or
high humidity may cause the cardboard sleeve to soften, impairing the tying functionality. Also
observe the information on the package provided by the tying material manufacturer.
INFORMATION
For trouble-free use in the field, KRONE recommends one of the "KRONE excellent" nets, see
label on the machine with the number 27016326*.
