8 Operation
8.20 Operating the central chain lubrication system
96
Comprima F 155
Original Operating Instructions 150001049_01_en
Pos. Designation
1 Bale formation conveyor drive
2 Bale formation conveyor drive
3 Roller drive feed roller
4 Pick-up/auger conveyor
Setting oil quantity
Loosen the screws(6).
Turn the eccentric cam(5) until the arrow is on the required oil quantity.
Tighten the screws(6).
