Environmental chambers TC30 and TC40 page 71
Connect the Quick-Lock connections at the ends of the hoses to a flow-through
thermostat.
11.5.2 Condensation protection
At a high relative humidity condensation could form on the viewing and measuring
window with measurements below room temperature. In order to prevent this, the
divided tube connectors are used to direct a stream of air through the chamber
and past the windows.
Measurements without heat conducting hood
Connect the tube attached to the top connectors to a compressed gas supply
(approx. 500 mbar).
Measurements with heat conducting hood:
Connect the tube attached to the top and bottom connectors to a compressed
gas supply (approx. 500 mbar).
