page 72 Environmental chambers TC30 and TC40
11.5.3 External temperature sensor
The temperature above the sample can be measured with the help of an external
temperature sensor.

If the heat conducting hood is used then this must be placed in position before
the temperature sensor is inserted.
 With the sample drawer closed, slide the sensor into the guide on the top of the
chamber.
!
Make sure that the inserted samples do not come into contact with the
sensor; if necessary pull the sensor out slightly.
 Connect the temperature sensor to the connector on the DSA100 provided for
the purpose ( Chapter 5.8).
11.5.4 Inert gas connector
SPAC S PA C S PAC SPAC
Use only inert gases such as nitrogen or argon. Do not use gases which are
harmful, poisonous, inflammable or corrosive.
SPAC S PA C S PAC SPAC
1. Remove the screw on the rear of the chamber.
2. Screw the connection socket supplied with the chamber into the thread.
