kruss DSA100 User Manual

Appendix page 105
V Addresses and mounting of the electronic module
EM3201
Depending on the dosing unit used, one, two or three electronics board must be
addressed, mounted and connected.
Va) Overview
The following table contains an overview for the electronic modules EM3201 to be
installed for the different dosing units.
Dosing unit Number of
EM3200
Addresses Slot assignment
DS3210 (Single
Direct Dosing)
1 4
1,2
DS3222 (2 syringes)
1 4
Module 1 (Adr. 4)
1,2: syringe revolver
3,4: syringe drivers 1, 2
DS3223 (3 syringes)
2 4, 5
Module 1 (Adr. 4)
1,2: syringe revolver
Module 2 (Adr. 5)
1,2,3: syringe drivers 1-3
DS3224 (4 syringes)
2 4, 5
Module 1 (Adr. 4)
1,2: syringe revolver
Module 2 (Adr. 5)
1,2,3,4: syringe drivers 1-
4
DS3225 (5 syringes)
2 4, 5
Module 1 (Adr. 4)
1,2: syringe revolver
3,4: syringe drivers 1, 2
Module 2 (Adr. 5)
1,2,3: syringe drivers 3-5
DS3226 (6 syringes)
2 4, 5
Module 1 (Adr. 4)
1,2: syringe revolver
3,4: syringe drivers 1, 2
Module 2 (Adr. 5)
1,2,3,4: syringe drivers 3-
6
