Appendix
page
93
IIIb)
Procedu
re
1.
Open both doors of the chambers on both sides of the
DS
A10
0
. If necessary,
remove the liquid containers and their racks from the c
hambers.
2.
In both chambers, a hexagon socket screw is situated behind the stand. Screw
out the screws in both chambers.
3.
Remove the cover that was fixed with the screw
s.
4.
Unscrew the middle cov
er. It is f
ixed with two hexago
n
so
cket screws on the
rear side and two screws on the inside.
