page 90 Appendix
SPAC S PA C S PAC SPAC
II Exchanging cameras
This chapter describes how to change between different camera frames.
Before changing a camera the drivers required for its use must be installed.
IIa) Assembly
1. Switch off the DSA100.
2. Open the doors of the chambers at the camera side (left).
3. Remove the covers from the camera housing. In order to do that, pull the spring
inside the chamber and lift up the cover.
For CF3220/21 and for IEEE-1394 cameras the camera cover has an outlet
for the cables at the rear side. Exchange the camera covers when changing
from CF3200/3201 camera to one of these cameras.
