page 82 Humidity chamber HC10
3. Push the HC10 over the environmental chamber from the rear as far as it will
go. Feed the tubes for the condensation protection through the openings in the
side.
4. Fix the HC10 to the environmental chamber. To do this, use the 4 longer screws
supplied with the HC10 in the holes in the environmental chamber which were
freed in Step 2.
left right
Preparing the TC30/40 heat conducting hood
KRÜSS recommends the use of the heat conducting hood. This reduces
variations in temperature and humidity.
Remove the plate on the rear of the heat conducting hood.
