Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-4-4
1020 MP feed sensor remaining
jam
MP feed sensor (MPFS) is turned on when the
power is turned on.
B
1403 PF feed sensor 1 non arrival
jam
PF feed sensor 1 (PFFS1) does not turn on during
paper feed from paper feeder 2.
F
1413 PF feed sensor 1 stay jam PF feed sensor 1 (PFFS1) does not turn off during
paper feed from paper feeder 2.
F
1420 PF feed sensor 1 remaining
jam
PF feed sensor 1 (PFFS1) is turned on when the
power is turned on.
F
1620 PF feed sensor 2 remaining
jam
PF feed sensor 2 (PFFS2) is turned on when the
power is turned on.
G
4002 Registration sensor non
arrival jam
The registration sensor (RS) does not turn on dur-
ing paper feed from paper feeder 1.
A
4003 The registration sensor (RS) does not turn on dur-
ing paper feed from paper feeder 2.
A
4009 The registration sensor (RS) does not turn on dur-
ing paper feed from MP tray.
A
4012 Registration sensor stay jam The registration sensor (RS) does not turn off dur-
ing paper feed from paper feeder 1.
C
4013 The registration sensor (RS) does not turn off dur-
ing paper feed from paper feeder 2.
C
4019 The registration sensor (RS) does not turn off dur-
ing paper feed from MP tray.
C
4020 Registration sensor remain-
ing jam
The registration sensor (RS) is turned on when the
power is turned on.
C
4201 Eject sensor non arrival jam The eject sensor (ES) does not turn on during
paper feed from cassette.
C
4202 The eject sensor (ES) does not turn on during
paper feed from paper feeder 1.
C
4203 The eject sensor (ES) does not turn on during
paper feed from paper feeder 2.
C
4208 The eject sensor (ES) does not turn on during
paper feed from duplex section.
C
4209 The eject sensor (ES) does not turn on during
paper feed from MP tray.
C
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-2 for paper jam location (see page 1-4-2).

Kyocera Ecosys M6526cdn Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Functions	Print, Copy, Scan, Fax
Fax Speed	33.6 kbps
Mobile Printing Support	Yes
Paper Output Capacity	150 sheets
Max Paper Size	A4
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Warm-up Time	29 seconds
Duty Cycle	50, 000 pages per month
Recommended Monthly Print Volume	Up to 3, 000 pages
First Copy Out Time	10 seconds
Zoom Range	25% - 400%
Scan to	Email, FTP, SMB, USB
Fax Resolution	300 x 300 dpi
Memory	512 MB
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
