Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-5-7
5. Open the memory cover and then
remove it.
Figure 1-5-10
6. Open the waste toner cover.
7. Push the lock release button and then
remove the waste toner box.
Figure 1-5-11
Memory cove
r
Waste toner box
Waste toner
cover
Lock release button

Kyocera Ecosys M6526cdn Specifications

General

Brand	Kyocera
Model	Ecosys M6526cdn
Category	All in One Printer
Language	English
