Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-5-47
11. Remove each three screws and then
remove laser scanner unit (KM, CY).
12. Check or replace the laser scanner unit
and refit all the removed parts.
Figure 1-5-71
Screw
Screw
Laser scanner
unit (CY)
Laser scanner
unit (KM)
Screw

Kyocera Ecosys M6526cdn Specifications

General

Brand	Kyocera
Model	Ecosys M6526cdn
Category	All in One Printer
Language	English
