Kyocera Ecosys M6526cdn Service Manual

2PV/2PW-3
2-3-18
YC107 1 VBUS O 5 V DC 5 V DC power output
Connected to
USB
2 DATA- I/O - USB data signal
3 DATA+ I/O - USB data signal
4 GND - - Ground
5 GND - - Ground
YC109
1
VDD5 O 3.3 V DC 3.3 V DC power
Connected to
e-KUIO slot
2
GND - - Ground
3
RESETN I 0/3.3 V DC Reset signal
4
VDD5_CUT O 3.3 V DC 3.3 V DC power
5
GND - - Ground
6
WAKEUP O 0/3.3 V DC Control signal
7
AUDIO I Analog Audio signal
8
RESERVE - - -
9
RESERVE - - -
10
RESERVE - - -
11
GND - - Ground
12
RESERVE - - -
13
RESERVE - - -
14
GND - - Ground
15
RESERVE - - -
16
RESERVE - - -
17
GND - - Ground
18
USB_DP I/O - USB data signal
19
USB_DN I/O - USB data signal
20
VBUS O 3.3 V DC 3.3 V DC power
YC119
A-1
VBUS O 5 V DC 5 V DC power output
Connected to
USB
A-2
DATA- I/O - USB data signal
A-3
DATA+ I/O - USB data signal
A-4
GND - - Ground
B-1
VBUS O 5 V DC 5 V DC power output
B-2
DATA- I/O - USB data signal
B-3
DATA+ I/O - USB data signal
B-4
GND - - Ground
Connector Pin Signal I/O Voltage Description
