Kyocera Ecosys M6526cdn Service Manual

2PV/2PW-3
2-3-19
YC2000
1 CD/DAT3 I/O 0/3.3 V DC Control signal
Connected to
SD card
2 CMD I/O 0/3.3 V DC Control signal
3 GND - - Ground
4 VDD - 0/3.3 V DC Control signal
5 CLK - 0/3.3 V DC Control signal
6 GND - - Ground
7 DAT0 I/O 0/3.3 V DC(pulse) Data bus signal
8 DAT1 I/O 0/3.3 V DC(pulse) Data bus signal
9 DAT2 I/O 0/3.3 V DC(pulse) Data bus signal
10 CD I 0/3.3 V DC Control signal
11 COMMON - 0/3.3 V DC Control signal
12 WP I 0/3.3 V DC Control signal
YC2004 1 TCT O 3.3 V DC 3.3 V DC power output
Connected to
ethernet
2 TD+ O 0/3.3 V DC (pulse) Transmission data
3 TD- O 0/3.3 V DC (pulse) Transmission data
4 RD+ I 0/3.3 V DC (pulse) Received data
5 RD- I 0/3.3 V DC (pulse) Received data
6 RCT O 3.3 V DC 3.3 V DC power output
7 CAT PHY O 0/3.3 V DC Control signal
8 ANO PHY O 3.3 V DC 3.3 V DC power output
9 CAT MAC - - Ground
10 ANO MAC O 0/3.3 V DC Control signal
Connector Pin Signal I/O Voltage Description
