Kyocera ECOSYS MA4500x

10-20
Troubleshooting > Troubleshooting
5
Start up the browser.
Enter "https://" and host name of the machine to access the Command Center RX.
6
Select [Device Information/Remote Operation] > [Remote Operation].
7
Click [Start] button.
When the Remote Operation is started up, the operation panel screen will be displayed on the system
administrator's or user's PC screen.
Executing Remote Operation from VNC Software
1
Display the screen.
[System Menu/Counter] key > [ ] [ ] key > [System/Network] > [OK] key > [ ] [ ] key >
[Network Setting] > [OK] key > [ ] [ ] key > [ProtocolSettings] > [OK] key
2
Set "Enhanced VNC (RFB)" to [On].
3
Startup the remote operation.
1 Start up the VNC software.
2 Enter the following format separated by a colon to start up the remote operation.
"IP address: port number"
Accessing Command Center RX (page 2-50)
NOTE
• If the user is logged in to the device, the permission confirmation screen will be displayed on the
operation panel. Select [Yes].
• If pop-up blocking of the browser occurs during connection of the Remote Operation, select Always allow
pop-ups from https:// [host name], and click Done. Perform Remote Operation after waiting 1 minute or more.
ProtocolSettings (page 8-14)
NOTE
• When setting "VNC (RFB) over SSL" to [On], the communication is encrypted.
• You can configure the protocol settings using Command Center RX.
Command Center RX User Guide
NOTE
When setting "VNC (RFB)" to [On] in step 2, the default port number is 9062. When setting "VNC (RFB)
over SSL " to [On], the default port number is 9063.
ProtocolSettings (page 8-14)
