7: Services
SLC™ 8000 Advanced Console Manager User Guide 95
2. Enter the following:
Enable Agent Enables or disables the Simple Network Management Protocol (SNMP) agent, which
allows read-only access to the system. Disabled by default.
Top Level MIB Click the link to access the top level MIB file for all Lantronix products.
SLC MIB Click the link to access the SLC MIB definition file for SLC 8000 advanced console
managers and advanced console managers.
Enable v1/v2c If checked, SNMP version 1 and version 2 (which use the Read-Only and Read-Write
Communities) are enabled. Uncheck to only allow the more secure version 3 to be
used to access the SLC unit via SNMP. The default is enabled.
Enable Traps Traps are notifications of certain critical events. Disabled by default. This feature is
applicable when SNMP is enabled. Traps that the SLC unit sends include:
 coldStart (generic trap 0, OID 1.3.6.1.6.3.1.1.5.1)
 linkDown (generic trap 2, OID 1.3.6.1.6.3.1.1.5.3)
 linkUp (generic trap 3, OID 1.3.6.1.6.3.1.1.5.4
 authenticationFailure (generic trap 4, OID 1.3.6.1.6.3.1.1.5.5)
 slcEventPowerSupply (1.3.6.1.4.1.244.1.1.0.1)
 slcEventSysadminPassword (1.3.6.1.4.1.244.1.1.0.2)
 slcEventSLCShutdown (1.3.6.1.4.1.244.1.1.0.3)
 slcEventDevicePortData (1.3.6.1.4.1.244.1.1.0.4)
 slcEventDevicePortSLMData (1.3.6.1.4.1.244.1.1.0.5)
 slcEventDevicePortSLMConfig (1.3.6.1.4.1.244.1.1.0.6)
 slcEventDevicePortDeviceLowTemp (1.3.6.1.4.1.244.1.1.0.7)
 slcEventDevicePortDeviceHighTemp (1.3.6.1.4.1.244.1.1.0.8)
 slcEventDevicePortDeviceLowHumidity (1.3.6.1.4.1.244.1.1.0.9)
 slcEventDevicePortDeviceHighHumidity (1.3.6.1.4.1.244.1.1.0.10)
 slcEventDevicePortDeviceError (1.3.6.1.4.1.244.1.1.0.11)
 slcEventUSBAction (1.3.6.1.4.1.244.1.1.0.14)
 slcEventInternalTemp (1.3.6.1.4.1.244.1.1.0.13)
 slcEventDevicePortError (1.3.6.1.4.1.244.1.1.0.15)
 slcEventSDCardAction (1.3.6.1.4.1.244.1.1.0.16)
 slcEventNoDialToneAlarm (1.3.6.1.4.1.244.1.1.0.17)
 slcEventDevicePortDeviceContactChanged (1.3.6.1.4.1.244.1.1.0.20)
 slcEventSFPAction (1.3.6.1.4.1.244.1.1.0.21)
The SLC unit sends the traps to the host identified in the NMS #1 and NMS #2 field
using the selected Trap Version.
For information on these traps, view the SLC enterprise MIB, which is available on the
SNMP web page.
Trap Version When traps are sent, which SNMP version to use when sending the trap: v1, v2c or v3.
The default is v2c.
NMS #1 (or #2) When SNMP is enabled, an NMS (Network Management System) acts as a central
server, requesting and receiving SNMP-type information from any computer using
SNMP. The NMS can request information from the SLC 8000 advanced console
manager and receive traps from the SLC unit. Enter the IPv4 or IPv6 address of the
NMS server. At least NMS #1 is required if you selected Enable Traps.
Alarm Delay Number of seconds delay between outgoing SNMP traps.
Engine ID The unique SNMP engine identifier for the SLC. This identifier may be required by the
NMS in order to received v3 traps.
Location Physical location of the SLC 8000 advanced console manager (optional). Useful for
managing the SLC unit using SNMP. Up to 20 characters.
Contact Description of the person responsible for maintaining the SLC 8000 advanced console
manager, for example, a name (optional). Up to 20 characters.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
