Lantronix SLC 8000 User Manual

7: Services
SLC™ 8000 Advanced Console Manager User Guide 103
Figure 7-5 IP Address Login Page
To directly access the CLI interface for a device:
1. Click the SSH or Telnet link in the SSH/Telnet to CLI column directly beside the port you
would like to access.
Note: For SLC console managers with 7.2.0.0 firmware releases and earlier, an
SSH or Telnet popup window for Java appears (see Figure 7-6) before login. Click OK
to dismiss this popup window and continue on to the login. For SLC console
managers with 7.3.0.0 firmware releases and later, the SSH or Telnet popup window
is bypassed and you are brought directly to the login in a non-Java based browser
window (see Figure 7-7). For tips on troubleshooting browser issues for the non-Java
based Web SSH/Telnet application, see Browser Issues (on page 105).
Figure 7-6 SSH and Telnet Opening File Popups
2. Click your mouse into the CLI login interface that appears and login. The CLI interface will
indicate when your connection is established.
3. When using the non-Java Web SSH or Web Telnet window, to terminate the session, use
either the host's logoff command. You may also use ^] to terminate a Telnet session or ~. to
terminate an SSH session.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
