Lantronix SLC 8000 User Manual

12: User Authentication
SLC™ 8000 Advanced Console Manager User Guide 260
Host and Login for Export
To view or delete a key:
1. Select the key from the appropriate table. The View and Delete buttons become active.
2. To view the key, click the View button. A pop-up page displays the key.
Imported key for sysadmin@DaveSLM:
ssh-rsa AAAAB3NzaC1yc2EAAAABIwAAAIEAxGxPGY9HsG9VqroDo98B89Cf
haqB6jG//0tTMKkb3zrpPu0HHAXaiVXHAvv7lAte31VTpoXdLAXN0uCvuJLf
aL/LvvGmoEWBuBSu505lQHfL70ijxZWOEVTJGFqUQTSq8Ls3/v3lkUJEX5ln
2AlQx0F40I5wNEC0+m3d5QE+FKc= sysadmin@DaveSLM
3. To delete the key, click the Delete button.
To view, reset, or import SSH RSA1, RSA, And DSA host keys:
1. On the User Authentication - SSH Keys page, click the SSH Server/Host Keys link at the
top right. The following page displays the current host keys. In the example below, the current
keys are the defaults.
Key Name Name of the key. This will generate the public key filename (e.g., <keyname>.pub).
Key Type Select either the RSA or the DSA encryption standard. RSA is the default.
Number of Bits Select the number of bits in the key (1024, 2048, 3072, or 4096). The default is
2048.
Passphrase / Retype
Passphrase
Optionally, enter a passphrase associated with the key. The passphrase may have
up to 50 characters. The passphrase is an optional password that can be
associated with an SSH key. It is unique to each user and to each key.
See Key Sequences for notes on key sequence precedence and behavior.
SECSH Format Indicate whether the keys will be exported in SECSH format (by default the key is
exported in OpenSSH format).
Public Key Filename Filename of the public host key.
Export via Select the method (SCP, SFTP, FTP, HTTPS, or Copy/Paste) of exporting the key
to the remote server. Copy/Paste, the default, requires no other parameters for
export.
Host IP address of the remote server to which the SLC 8000 advanced console manager
will SCP, SFTP or FTP the public key file.
Path Optional path of the file on the host to SCP, SFTP or FTP the public key too.
Login User ID to use to SCP, SFTP or FTP the public key file.
Password /
Retype Password
Password to use to SCP, SFTP or FTP the public key file.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
