Lantronix SLC 8000 User Manual

7: Services
SLC™ 8000 Advanced Console Manager User Guide 108
Figure 7-10 Services > Date & Time
2. Enter the following:
3. To save, click the Apply button.
To synchronize the SLC 8000 advanced console manager with a remote timeserver using
NTP:
1. Enter the following:
Change Date/Time
Select the checkbox to manually enter the date and time at the
SLC location.
Date From the drop-down lists, select the current month, day, and year.
Time From the drop-down lists, select the current hour and minute.
Time Zone From the drop-down list, select the appropriate time zone. For information on each
timezone, see http://en.wikipedia.org/wiki/List_of_tz_database_time_zones
Enable NTP Select the checkbox to enable NTP synchronization. NTP is disabled by default.
Current NTP status Displays the current NTP status if NTP is enabled above.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
