Lantronix SLC 8000 User Manual

7: Services
SLC™ 8000 Advanced Console Manager User Guide 106
To configure how secure Lantronix devices are searched for on the network:
1. Click the Search Options link on the top right of the Services > Secure Lantronix Network
page. The following web page displays:
Figure 7-9 Services > Secure Lantronix Network > Search Options
2. Enter the following:
3. If you entered an IP address, click the Add IP Address button. The IP address displays in the
IP Address List.
4. Repeat steps 2 and 3 for each IP address you want to add.
5. To delete an IP address from the IP Address List, select the address and click the Delete IP
Address button.
6. Click the Apply button. When the confirmation message displays, click Secure Lantronix
Network on the main menu. The Services > Secure Lantronix Network page displays the
secure Lantronix devices resulting from the search. You can now manage these devices.
Secure Lantronix
Network Search
Select the type of search you want to conduct.
 Local Subnet performs a broadcast to detect secure Lantronix devices on the
local subnet.
 Manually Entered IP Address List provides a list of IP addresses that may not
respond to a broadcast because of how the network is configured.
 Both is the default selection.
IP Address If you selected Manually Entered IP Address List or Both, enter the IP address of
the secure Lantronix device you want to find and manage.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
