Figure 114. Connecting M.2 backplane cables to system board
1 M.2 signal connector
2 M.2 power connector
After you finish
Complete the parts replacement. See “Complete the parts replacement” on page 328.
Memory module replacement
Use the following procedures to remove and install a memory module.
