After you finish
1. Reconnect the power and signal cables to the 2.5-inch or 3.5-inch drive backplane.
2. Reinstall the drives and drive bay fillers (if any) into the drive bays. See “Install a 2.5-/3.5-inch hot-swap
drive” on page 230.
3. Complete the parts replacement. See “Complete the parts replacement” on page 328.
EDSFF hot-swap drive replacement
Follow instructions in this section to remove and install an EDSFF hot-swap drive.
Remove an EDSFF hot-swap drive
Follow instructions in this section to remove an EDSFF hot-swap drive.
About this task
Attention:
• Read “Installation Guidelines” on page 121 and “Safety inspection checklist” on page 122 to ensure that
you work safely.
• To make sure that there is adequate system cooling, do not operate the solution for more than two
minutes without either a drive or a filler installed in each bay.
• If one or more EDSFF drives are to be removed, it is recommended to disable them beforehand via the
operating system.
• Before you remove or make changes to drives, drive controllers (including controllers that are integrated
on the system board), drive backplanes or drive cables, back up all important data that is stored on drives.
• Before you remove any component of a RAID array (drive, RAID card, etc.), back up all RAID configuration
information.
Note: Make sure you have the drive bay fillers available if some drive bays will be left empty after the
removal.
Watch the procedure. A video of the installation and removal process is available:
• YouTube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-BXei6L6c05osQVLt4w5XYx
• Youku: https://list.youku.com/albumlist/show/id_59636529
Procedure
Step 1. Hold the handle of the EDSFF drive cage cover and pull it out of the server.
Chapter 4. Hardware replacement procedures 239
