Lenovo ThinkSystem SR670 V2 - System-Board Connectors

System Environmental Information
Sub Menu
Example
• Ambient temperature
• Exhaust temperature
• PSU status
• Spinning speed of fans by RPM
Ambient Temp: 24 C
Exhaust Temp: 30 C
PSU1: Vin= 213 w
Inlet= 26 C
FAN1 Front: 21000 RPM
FAN2 Front: 21000 RPM
FAN3 Front: 21000 RPM
FAN4 Front: 21000 RPM
Active Sessions
Sub Menu
Example
Quantity of active sessions
Active User Sessions: 1
Actions
Sub Menu Example
Several quick actions are available:
• Restore XCC to Defaults
• Force XCC Reset
• Request XCC Reset
• Set UEFI Memory Test
• Clear CMOS
• Request Virtual Reseat
• Modify XCC Static IPv4 Address/Net mask/Gateway
• Modify System Name
• Generate/Download FFDC Service Data
Request XCC Reset?
This will request the BMC to reboot itself.
Hold √ for 3 seconds
System-board layout
The illustrations in this section provide information about the connectors and switches that are available on
the system board.
For more information about the LEDs that are available on the system board, see “System-board LEDs” on
page 342.
System-board connectors
The following illustrations show the internal connectors on the system board.
34
ThinkSystem SR670 V2 Maintenance Manual
