System Environmental Information
Sub Menu
Example
• Ambient temperature
• Exhaust temperature
• PSU status
• Spinning speed of fans by RPM
Ambient Temp: 24 C
Exhaust Temp: 30 C
PSU1: Vin= 213 w
Inlet= 26 C
FAN1 Front: 21000 RPM
FAN2 Front: 21000 RPM
FAN3 Front: 21000 RPM
FAN4 Front: 21000 RPM
Active Sessions
Sub Menu
Example
Quantity of active sessions
Active User Sessions: 1
Actions
Sub Menu Example
Several quick actions are available:
• Restore XCC to Defaults
• Force XCC Reset
• Request XCC Reset
• Set UEFI Memory Test
• Clear CMOS
• Request Virtual Reseat
• Modify XCC Static IPv4 Address/Net mask/Gateway
• Modify System Name
• Generate/Download FFDC Service Data
Request XCC Reset?
This will request the BMC to reboot itself.
Hold √ for 3 seconds
Power supply LEDs
This topic provides information about various power supply LED status and corresponding action
suggestions.
The following minimum configuration is required for the server to start:
• Two processors in socket 1 and 2
• Two DRAM memory modules in slots 14 and 30
• Two power supplies in bay 1 and 2
• One boot drive, M.2, 2.5-inch, 3.5-inch, or EDSFF drive, and RAID adapter if configured. (If OS is needed
by debugging)
• Five system fans
The following table describes the problems that are indicated by various combinations of the power-supply
LEDs and the power-on LED on the front operator panel and suggested actions to correct the detected
problems.
Chapter 5. Problem determination 341
