The parts listed in the following table are identified as one of the following:
• Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your responsibility. If Lenovo
installs a Tier 1 CRU at your request with no service agreement, you will be charged for the installation.
• Tier 2 customer replaceable unit (CRU): You may install a Tier 2 CRU yourself or request Lenovo to
install it, at no additional charge, under the type of warranty service that is designated for your server.
• Field replaceable unit (FRU): FRUs must be installed only by trained service technicians.
• Consumable and Structural parts: Purchase and replacement of consumable and structural parts
(components, such as a cover or bezel) is your responsibility. If Lenovo acquires or installs a structural
component at your request, you will be charged for the service.
Table 21. Parts list of the SXM GPU Model
Index Description
Tier 1 CRU Tier 2 CRU
FRU
Consuma-
ble and
Structural
part
For more information about ordering the parts shown in Figure 18 “Server components” on page 52:
1. Go to
https://datacentersupport.lenovo.com/tw/en/products/servers/thinksystem/sr670v2/7z22/parts/display/
compatible
and navigate to the support page for your server.
2. Enter either the serial number or the machine type model for your server to see the parts for your server.
It is highly recommended that you check the power summary data for your server using Lenovo Capacity Planner
before purchasing any new parts.
1
Top cover
√
2
Processor heat sink
√
3
Heat sink Torx T30
√
4
Processor
√
5
DIMM filler
√
6
Persistent Memory (PMEM)
√
7
DRAM DIMM
√
8
SXM GPU power distribution board
√
9
Power distribution board
√
10
TPM card (Chinese Mainland only)
√
11
CMOS battery (CR2032)
√
12
System board
√
13
Intrusion switch
√
14
Cable guide
√
15
Power supply unit
√
16
Power supply unit filler
√
17
Cable
√
18
OCP Ethernet adapter
√
19
OCP Ethernet adapter filler
√
Chapter 2. Server components 53
