OCP Ethernet adapter cable routing
Connect the OCP Ethernet adapter signal cable as illustrated.
Figure 36. OCP Ethernet adapter cable routing – Configuration A with HBA/RAID adapter
From To
System board 1 PCIe connector 14 System board 1 PCIe connector 1
76 ThinkSystem SR670 V2 Maintenance Manual
