OCP Ethernet adapter cable routing
Connect the OCP Ethernet adapter signal cable as illustrated.
Figure 44. OCP Ethernet adapter cable routing – Configuration B
From To
System board 1 PCIe connector 14 System board 1 PCIe connector 1
Chapter 3. Internal cable routing 87
