Technical data
Operation with rated power (normal operation)
Rated data for 400 V mains voltage
3

138
EDKVF9333V DE/EN/FR 7.2
9300 Rated output current at switching frequency Max. permissible output current at switching
frequency
1)
2/4 kHz
3)
8 kHz 8 kHz sin 8/2 kHz
2)
16 kHz 2/4 kHz 8 kHz 8 kHz sin 8/2 kHz
2)
16 kHz
Type I
r
[A] I
r
[A] I
r
[A] I
r
[A] I
r
[A] I
max
[A] I
max
[A] I
max
[A] I
max
[A] I
max
[A]
EVF9321−xV 1.5 1.5 1.5 1.5 1.1 2.2 2.2 2.2 2.2 1.6
EVF9322−xV 2.5 2.5 2.5 2.5 1.8 3.7 3.7 3.7 3.7 2.7
EVF9323−xV 3.9 3.9 3.9 3.9 2.9 5.8 5.8 5.8 5.8 4.3
EVF9324−xV 7.0 7.0 7.0 7.0 5.2 10.5 10.5 10.5 10.5 1.8
EVF9325−xV 13.0 13.0 13.0 13.0 9.7 19.5 19.5 19.5 19.5 14.5
EVF9326−xV 23.5 23.5 23.5 23.5 15.2 35.0 35.0 35.0 35.0 22.9
EVF9327−xV 32.0 32.0 29.0 32.0 21.0 48.0 48.0 43.0 48.0 31.0
EVF9328−xV 47.0 47.0 43.0 47.0 30.0 70.5 70.5 64.0 70.5 46.0
EVF9329−xV 59.0 59.0 47.0 59.0 35.0 89.0 89.0 70.0 89.0 53.0
EVF9330−xV 89.0 89.0 59.0 89.0 46.0 134 134 88.0 134 69.0
EVF9331−xV 110 110 76.0 110 52.0 165 165 114 165 165
EVF9332−xV 150 147 92.0 150 58.0 225 221 138 225 87.0
EVF9333−xV 180 147 100 180 63.0 270 221 150 270 94.0
Bold print = Lenze setting
1)
The currents apply to a periodic load change with an overcurrent time of maximally 1 minute and a base load time
of 2 minutes with maximally 75 % I
rated
2)
Power−optimised operation with automatic switching frequency reduction. When the max. permissible output
current is exceeded, the switching frequency is reduced to 2 kHz.
3)
Possible for some types in case of other operating conditions: Operation with increased rated output current at the
same load change (see chapter "Operation with increased rated power")
