Mechanical installation
Standard devices in the power range 0.37 ... 11 kW
Mounting in "cold plate" technique
4
146
EDKVF9333V DE/EN/FR 7.2
4.1.4 Mounting in "cold plate" technique
The drive controllers can be mounted in ˜cold plate˜ technique, e.g. on collective coolers.
For this purpose, the drive controllers of type EVF93xx−CV must be used.
Required mounting material from the scope of supply:
Description Use
EVF9321
EVF9322
EVF9323
EVF9324
EVF9325
EVF9326
Quantity
Fixing bracket Drive controller fixing 2 2 2
Sheet metal screw
3.5 × 13 mm (DIN 7981)
Mounting of fixing bracket to
the drive controller
6 6 6
Requirements for collective coolers
The following points are important for safe and reliable operation of the controller:
ƒ Good thermal connection to the cooler
– The contact surface between the collective cooler and the controller must be at
least as large as the cooling plate of the controller.
– Plane contact surface, max. deviation 0.05 mm.
– When attaching the collective cooler to the controller, make sure to use all
specified screw connections.
ƒ Observe the thermal resistance R
th
given in the table. The values are valid for
controller operation under rated conditions.
9300 Cooling path
Power to be dissipated Heatsink − environment
Type P
v
[W] R
th
[K/W]
EVF9321−CV 24 1.45
EVF9322−CV 42 0.85
EVF9323−CV 61 0.57
EVF9324−CV 105 0.33
EVF9325−CV 180 0.19
EVF9326−CV 360 0.10
Ambient conditions
ƒ The rated data and the derating factors at increased temperature also apply to the
ambient temperature of the drive controllers.
ƒ Temperature at the cooling plate of the drive controller: max. 75 °C.
