Mechanical installation
Standard devices with a power of 45 kW
Important notes
4
153
EDKVF9333V DE/EN/FR 7.2
4.3 Standard devices with a power of 45 kW
4.3.1 Important notes
The accessory kit is located inside the controller.
Remove the cover of the drive controller
0
1
1. Remove the screws
2. Lift cover up and detach it
9300vec113
Mass of the devices
9300 Standard device "Cold plate" device
Type EVF93xx−EV
[kg]
EVF93xx−CV
[kg]
EVF9330−xV 36.0 ˘
