Lenze 9300 vector Series Mounting Instructions

Electrical installation
Standard devices in the power range of 55 kW
Mains choke/mains filter assignment
5

191
EDKVF9333V DE/EN/FR 7.2
Installation to UL
Supply conditions
Range Description
Fuses l Only according to UL 248
l Mains short−circuit current up to 10000 A
rms
: All classes permissible
l Mains short−circuit current up to 50000 A
rms
: Only classes "J", "T" or "R" permissible
Cables l Only in accordance with UL
l The cable cross−sections specified in the following apply under the following conditions:
– Conductor temperature < 60 °C
– Ambient temperature < 40 °C
Observe all national and regional regulations!
Operation at rated power
9300 Rated fuse current Cable cross−section
Fuse L1, L2, L3, PE
Type [A] [AWG]
Operation with mains choke/mains filter
EVF9330−xV
100 1
EVF9331−xV 125 1/0
5.6.4 Mains choke/mains filter assignment
Operation at rated power
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9330−xV ELN3−0038H085
EZN3A0037H090 25 E82ZN45334B230 10
E82ZN45334B230 50 EZN3B0037H090 50
EVF9331−xV ELN3−0027H105−001
EZN3A0030H110 25
E82ZN55334B230 10
EZN3A0030H110N001
3)
25
E82ZN55334B230 50 EZN3B0030H110 50
3)
For controllers with thermal separation
Operation with increased rated power
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9330−xV ELN3−0027H105−001 EZN3A0030H110 25
E82ZN55334B230 10
EZN3B0030H110N001
3)
25
E82ZN55334B230 50 EZN3B0030H110 50
EVF9331−xV ELN3−0027H105−001
EZN3A0030H110 25
EZN3B0030H110 50
EZN3A0030H110N001
3)
25
3)
For controllers with thermal separation
