Technical data
Operation with increased rated power
Rated data for 400 V mains voltage
3
141
EDKVF9333V DE/EN/FR 7.2
3.4 Operation with increased rated power
Note!
ƒ The operation with increased rated power is not UL−certified.
ƒ Operation with increased rated power is only allowed:
– In the listed mains voltage range
– With the listed switching frequencies
– With the specified fuses, cable cross−sections and mains chokes or mains
filters
3.4.1 Rated data for 400 V mains voltage
Basis of the data
Voltage Frequency
AC mains connection [U
N
] 3/PE AC 320 V − 0 % ... 440 V + 0 % 45 Hz − 0 % ... 65 Hz + 0 %
DC−mains connection
(alternatively)
[U
DC
] DC 450 V − 0 % ... 620 V + 0 % ˘
Output voltage
With mains choke 3 ~ 0 approx. 94 % V
rated
˘
9300 Mains current
1)
Typical motor power Output power Power loss
ASM
(4−pole)
2/4 kHz
2)
U, V, W +U
G
, −U
G
3)
Type I
r
[A] P
rated
[kW] P
rated
[hp] S
rated
[kVA] P
DC
[kW] P
loss
[W]
EVF9321−xV 1.7 0.55 0.75 1.3 1.72 50
EVF9322−xV 2.8 1.1 1.5 2.1 0.35 65
EVF9323−xV 5.0 2.2 3.0 3.8 0 115
EVF9324−xV 8.8 4.0 5.0 6.5 1.0 165
EVF9325−xV 15.0 7.5 10.0 11.1 0 260
EVF9327−xV 39.0 22.0 30.0 29.8 3.2 640
EVF9328−xV 50.0 30.0 40.0 39.5 0 810
EVF9329−xV 60.0 37.0 50.0 46.4 0 950
EVF9330−xV 97.0 55.0 75.0 74.8 0 1350
EVF9331−xV 119 75.0 100 91.5 0 1470
EVF9332−xV 144 90.0 125 110 13.1 2100
EVF9333−xV 185 110.0 150 142 20.6 2400
1)
Mains currents at a switching frequency of 2/4 kHz
2)
Switching frequency of the inverter
3)
Power supplied by the DC bus when operating with power−adapted motor
