Technical data
Operation with rated power (normal operation)
Rated data for 480 V mains voltage
3

140
EDKVF9333V DE/EN/FR 7.2
9300 Rated output current at switching frequency Max. permissible output current at switching
frequency
1)
2/4 kHz 8 kHz 8 kHz sin 8/2 kHz
2)
16 kHz 2/4 kHz 8 kHz 8 kHz sin 8/2 kHz
2)
16 kHz
Type I
r
[A] I
r
[A] I
r
[A] I
r
[A] I
r
[A] I
max
[A] I
max
[A] I
max
[A] I
max
[A] I
max
[A]
EVF9321−xV 1.5 1.5 1.5 1.5 1.1 2.2 2.2 2.2 2.2 1.6
EVF9322−xV 2.5 2.5 2.5 2.5 1.8 3.7 3.7 3.7 3.7 2.7
EVF9323−xV 3.9 3.9 3.9 3.9 2.9 5.8 5.8 5.8 5.8 4.3
EVF9324−xV 7.0 7.0 7.0 7.0 5.2 10.5 10.5 10.5 10.5 7.8
EVF9325−xV 13.0 13.0 13.0 13.0 9.7 19.5 19.5 19.5 19.5 14.5
EVF9326−xV 22.3 22.3 22.3 22.3 14.6 33.5 33.5 33.5 33.5 21.8
EVF9327−xV 30.4 30.4 27.0 30.4 19.0 45.6 45.6 41.0 45.6 29.0
EVF9328−xV 44.7 44.7 41.0 44.7 29.0 67.0 67.0 61.0 67.0 43.5
EVF9329−xV 56.0 56.0 44.0 560 33.0 84.0 84.0 66.0 84.0 49.0
EVF9330−xV 84.0 84.0 55.0 84.0 43.7 126 126 82.0 126 65.6
EVF9331−xV 105 105 71.0 105 49.5 157 157 107 157 74.0
EVF9332−xV 142 142 87.0 142 55.0 213 213 130 213 83.0
EVF9333−xV 171 171 94.0 171 59.0 256 211 141 256 89.0
Bold print = Lenze setting
1)
The currents apply to a periodic load change with an overcurrent time of maximally 1 minute and a base load time
of 2 minutes with maximally 75 % I
rated
2)
Power−optimised operation with automatic switching frequency reduction. When the max. permissible output
current is exceeded, the switching frequency is reduced to 2 kHz.
