Page #199 background image
Electrical installation
Standard devices in the power range 75 ... 90 kW
Mains choke/mains filter assignment
5
199
EDKVF9333V DE/EN/FR 7.2
Installation to UL
Supply conditions
Range Description
Fuses l Only according to UL 248
l Mains short−circuit current up to 10000 A
rms
: All classes permissible
l Mains short−circuit current up to 50000 A
rms
: Only classes "J", "T" or "R" permissible
Cables l Only in accordance with UL
l The cable cross−sections specified in the following apply under the following conditions:
Conductor temperature < 60 °C
Ambient temperature < 40 °C
Observe all national and regional regulations!
Operation at rated power
9300 Rated fuse current Cable cross−section
Fuse L1, L2, L3, PE
Type [A] [AWG]
Operation with mains choke/mains filter
EVF9332−xV
175 2/0
EVF9333−xV 200 3/0
5.7.4 Mains choke/mains filter assignment
Operation at rated power
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9332−xV ELN3−0022H130
EZN3A0022H150 25 E82ZN75334B230 10
E82ZN75334B230 50 EZN3B0022H150 50
EVF9333−xV ELN3−0017H170
EZN3A0017H200 25 E82ZN90334B230 10
E82ZN90334B230 50 EZN3B0017H200 50
Operation with increased rated power
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9332−xV ELN3−0017H170
EZN3A0017H200 25 E82ZN90334B230 10
E82ZN90334B230 50 EZN3B0017H200 50
EVF9333−xV ELN3−0014H200
EZN3A0015H230 25 EZN3B0015H230 50
EZN3A0017H200 25 EZN3B0017H200 50
