Lexmark 4036-307 - Page 110

5-4 Service Manual
4036-307, -308
J2
(cont)
21 GND
22 FBR_AFE_D7
23 FBR_AFE_D6
24 GND
25 FBR_AFE_D5
26 FBR_AFE_D4
27 GND
28 FBR_AFE_D3
29 FBR_AFE_D2
30 GND
31 FBR_AFE_D1
32 FBR_AFE_D0
33 GND
34 FBR_AFE_SEN
35 FBR_AFE_SCK
36 FBR_AFE_SDI
J7 1 +12 V
2GND
3GND
4+5 V
J13 1 +5 V
2GND
3 +3.3 V
4 +3.3 V
5MOD_D0
6MOD_D1
7MOD_D2
8MOD_D3
9GND
10 MOD_D4
11 MOD_D5
12 MOD_D6
13 MOD_D7
14 GND
15 MOD_DA0
16 MOD_DA1
17 MOD_DA2
18 GND
19 MOD_DA3
20 MOD_DA4
Scanner control board
Conn-
ector
Pin
no.
Signal
