Lexmark 4036-307 - Page 111

Connector locations 5-5
4036-307, -308
J13
(cont)
21 MOD_DA5
22 GND
23 MOD_IRQ
24 MOD_WR
25 MOD_RD
26 MOD_CS
27 GND
28 MOD_RDY
29 MOD_PRES
30 MOD_RES
J15 1 UI_RESET_NR
2GND
3TX1-
4TX1+
5TX2-
6TX2+
7CLKTX-
8CLKTX+
9GND
10 GND
11 RXD232_N
12 TXD232_N
13 TX0-
14 TX0+
15 GND
16 GND
17 24 V_LAMP_UI
18 24 V_LAMP_UI
J28 1 ADF_LAMP_ON_R
2 ADF_POWER_SAVE_R
3 24 V_ADF
4 24 V_ADF
5 ADF_CCD_BW_SEL_R
6GND
7 ADFR_CCD_TRANS
8GND
9 ADF_CCD_PHASE1_R
10 GND
Scanner control board
Conn-
ector
Pin
no.
Signal
