Lexmark 4036-307 - Page 112

5-6 Service Manual
4036-307, -308
J28
(cont)
11 ADF_CCD_RESET_R
12 GND
13 ADF_CCD_CLAMP_R
14 GND
15 ADF_AFE_CLK_R
16 GND
17 ADF_AFE_RSMP_R
18 GND
19 ADF_AFE_VSMP_R
20 GND
21 ADFR_AFE_D7
22 ADFR_AFE_D6
23 GND
24 ADFR_AFE_D5
25 ADFR_AFE_D4
26 GND
27 ADFR_AFE_D3
28 ADFR_AFE_D2
29 GND
30 ADFR_AFE_D1
31 ADFR_AFE_D0
32 GND
33 ADFR_AFE_SEN
34 ADFR_AFE_SCK
35 ADFR_AFE_SDI
36 CCD_DET_R
J46 1 +24 V
2GND
3 PS_RC
J47 1 RX0_P0
2RX0_N0
3RX0_P1
4RX0_N1
5 TX0_P0
6 TX0_N0
7 TX0_P1
8 TX0_N1
9 PS_RC
10 GND
Scanner control board
Conn-
ector
Pin
no.
Signal
