Lexmark 4036-307 - Page 71

Repair information 4-9
4036-307, -308
3. Remove the lamp cover (B), and set it aside.
4. Note the position of the two leaf springs (C) on the right and left so you can replace them.
5. Remove the two screws (D).
6. Remove the metal shield.
B
CDD
