Chapter 9 - Operating Instructions Liebert Hipulse E User Manual
Procedure Single or '1+N' UPS System
Page 9-14 (07/04)
9.11 Setting the Battery Test
A software-controlled battery test facility can be initiated from the Operator Control Panel on an 'immediate' or
'periodic' basis. This test turns off the rectifier and runs the inverter (and load) from the battery for a predetermined
period. If the battery voltage falls below a preset minimum level prior to the termination of the test period a
'BATTERY: TEST FAILED' alarm is annunciated and the rectifier is immediately turned on to prevent the load
transferring to bypass and recharge the battery. This instructions given below initiates an immediate battery test.
For the following test to be 'meaningful' as part of the UPS commissioning procedure, the batteries should be fully
charged prior to the test being carried out. The UPS rectifier section must therefore be allowed to operate with the
battery connected for several hours to provide the battery with an adequate initial charge.
Caution
Do not continue with this procedure if the battery has not yet been charged
1. From the Default window press the ENTER key: the Main Menu Window will display.
2. Select 'FUNCTION' and press ENTER key.
3. When the PASSWORD has been completed press the ENTER key.
4. Select 'BATTERY TEST' and press ENTER key
5. Verify that the parameters entered in the battery test setup menu are appropriate. If not then enter the correct
setup parameters (FUNCTION⇒BATTERY TEST⇒SETUP).
6. Press ESC to return to the Battery test menu screen.
7. Using the 'UP' menu button, select 'YES'' (Y), then press ENTER to initiate an immediate battery test.
8. Step back to default screen, by continually pressing the ESC button and verify that the message: BATTERY
UNDER TEST is displayed. The green LED battery bargraph will indicate the remain battery time. Note: If the
UPS is allowed to run in this condition the battery bargraph LED's will progressively turn off indicating the
remaining autonomy time.
9. The battery will be tested for the selected 'DURATION' time after which the UPS will revert to normal
operation. Note: If the battery fails the test, the rectifier will immediately return to the float mode and the
'BATTERY: TEST FAILED' alarm will be displayed on the default screen.
