Liebert Hipulse E - 400 Kva UPS Module with 6 Pulse Rectifier (or 12 Pulse Rectifier) with Top Cable Entry Option

Installation Manual Liebert Hipulse E Chapter 6 – Installation Drawing
Single or '1+N' UPS System
(07/04) Page 6-15
6.1.14 400kVA UPS Module with 6 pulse rectifier (or 12 pulse rectifier) with Top Cable entry option
1. Removable grille and panels for
lifting with fork-lift truck.
2. Air inlet grille
3. Air exhaust
- 800 mm min. clearance above unit
required for air exhaust.
4. Operator control and display
panel
A
ll dimensions are in mm.
