Chapter 8- Operating Instructions Liebert Hipulse E User Manual
Single or '1+N' UPS System Operator Control and Display Panel
Page 8-6 (07/04)
8.1.2 The Menu Options
A map of the routes to the options offered by the menu is provided in figure below. Options include windows, which
show status information and windows which permit data to be entered, or parameters for equipment control to be set.
The menu map shows that the routes pass from the main menu through different intermediate windows to reach the
option targeted. The diagram shows each of the windows in the format in which it appears on the LCD screen. The
initializing, default & main menu windows are described below.
