Liebert Hipulse E - 300 Kva UPS Module with 6 Pulse Rectifier

Chapter 6 – Installation Drawing Liebert Hipulse E Installation Manual
Single or '1+N' UPS System
Page 6-2 (07/04)
6.1.1 300kVA UPS Module with 6 pulse rectifier
1. Removable grille and panels for
lifting with fork-lift truck.
2. Air inlet grille
3. Air exhaust
- 800 mm min. clearance above unit
required for air exhaust.
4. Operator control and display
panel
A
ll dimensions are in mm.
