User Manual Liebert Hipulse E Chapter 9 - Operating Instructions
Single or '1+N' UPS System Procedure
(07/04) Page 9-5
BATTERY C.B. OPEN
HH.MM.S DD.MM.YY
9.3 Procedure for UPS Start-Up: without power initially supplied to the load
This procedure should be followed when turning on the UPS from a fully powered down condition - i.e. where the load
is not being initially supplied at all. It is assumed that the installation is complete, the system has been commissioned by
authorized personnel and the external power isolators are closed. Refer to Fig. 9-1 for corresponding isolators Q1 to
Q4.
1. Open the UPS door(s) to gain access to the main power switches.
2. Close the Rectifier Power Switch Q1.
The Module Mimic LED's will indicate input supply a.c. present ( 2 - steady green ) and after approximately 20
seconds the Inverter output healthy ( 4 - steady green ) and Battery unavailable (3) will light and also red led (13)
will illuminate.
The Display screen will show the following:
Initializing Window: after first connecting power to the UPS and closing
the Q1 isolator, this message will appear on the LCD screen. It persists for
about five seconds while the control firmware is loaded. It is followed by a
screen showing various messages with the time and date on the bottom line.
Note: If input power is present but the display remains blank, then the
Micro Controller is not working, please contact your dealer for advice.
WARNING
THE FOLLOWING ACTION WILL APPLY POWER TO THE LOAD EQUIPMENT -
ENSURE THAT IT IS SAFE TO DO SO.
3. Close the UPS output power switch Q4.
The Module Mimic LED's will change so that the Load on inverter ( 5 - steady green ) and Battery unavailable (3)
will light and also red led (13) will illuminate.
Note: In ECOMODE the Load on inverter led (5) is off.
The display window will show:
4. Close the Bypass input power switch Q2.
Bypass input Led ( 1 – steady green ) will light, after 20 seconds the inverter synchronises with the mains bypass.
5. Before closing the battery circuit breaker check the d.c. bus-bar voltage. From the above window press the
ENTER key:
LIEBERT
UPS
BYPASS SWITCH OPEN
BATTERY C.B. OPEN
OUTPUT SWITCH OPEN
HH.MM.SS DD.MM.YY
BATTERY C.B. OPEN
BYPASS SWITCH OPEN
HH.MM.S DD.MM.YY
