Liebert Hipulse E - Distance from Floor to Connection Point on the Equipment

Installation Manual Liebert Hipulse E Chapter 2 - Installation Procedure
Single or '1+N' UPS System Installation (Electrical)
(07/04) Page 2-9
2.2 Distance from floor to connection point on the equipment:
UPS
UPS
300 kVA
minimum distance (mm)
UPS
400 kVA
minimum distance (mm)
Rectifier a.c. Input supply
345 360
Bypass a.c. Input supply
345 480
UPS Output a.c.
345 800
Battery Power
345 460
Auxiliary cables: Battery Control / Temp.
Compensation (X3)
570 330
Communications to AS400/External Alarm
monitor
750 350
Remote Emergency Power Off (EPO) (X4)
450 400
Earth 350 360
Table 2-2
