Liebert Hipulse E - UPS Mechanical Characteristics

Chapter 5 – ‘Specification’ Liebert Hipulse E Installation Manual
Single or '1+N' UPS System
Page 5-2 (07/04)
5.3 UPS Mechanical Characteristics
MECHANICAL
CHARACTERISTICS
UNITS
UPS
300 kVA (6 pulse ) 300 kVA (12 pulse)
400 kVA
(6 pulse )
400 kVA
(12 pulse)
Section UPS 12 pulse Rect./St. Inverter Rect./St Inverter
Height
1900
Width of each section
1640 1640 640 1230
1230
Total width
1640 2280
2460
Total width including top cable
entry option
2280 2920
3100
Depth
mm
856
Weight of each section
1810 730
640
1750 1310 1750
Total weight without Input Filter
1850
2540
2390 3060
Total weight with Input Filter
“ “ “
(
filter 4%
)
2650
3192
“ “ “
(
filter 9%
)
kg
2010 2574
Ventilation - By internal extract fans
Airflow m
3
/h
4500 5000
8000
Cable entry - Bottom or either side (top optional)
Colour - RAL 7035 (Light grey)
Protection level (with open/closed
front doors)
IP 20
Note: Dimensions and weight do not include the pallet and packing material. Actual weight will vary depending on
installed options.
OPTION
MAINTENANCE BYPASS CABINET
1+ 1 Configuration (two UPS's with parallel redundant connection)
Height
1900
Width
900
Depth
mm
856
Weight kg
300
Cable entry - Top and bottom or either side
Colour - RAL 7035 (Light grey)
Protection grade
- IP 20
Power isolators
SIRCO 4 poles 630A (at 400 Vca)
