Installation Manual Liebert Hipulse E Chapter 5 – ‘Specification’
Single or '1+N' UPS System
(07/04) Page 5-3
5.4 UPS Electrical Characteristics (Input Rectifier)
RECTIFIER INPUT MAINS
UNITS
Rated power kVA 300 (6 pulse ) 300 (12 pulse) 400 (6 pulse ) 400 (12 pulse)
Rated mains voltage
Vac 380 - 400 - 415 V
Supply Three phase without neutral
Input voltage
tolerance
% -15, +10
Frequency
Hz 50 / 60
Input frequency
tolerance
% ± 5
321 304 431 410
Rated input power
with input harmonic
filter
kVA
276 with Input Filter
(9%)
304 with Input Filter
(4%)
371 with Input Filter
(9%)
410 with Input Filter
(4%)
463 438 622 591
Rated input current
with input harmonic
filter
A
399 with Input Filter
(9%)
439 with Input Filter
(4%)
535 with Input Filter
(9%)
591 with Input Filter
(4%)
405 384 540 520
Maximal input
power
with input harmonic
filter
kVA
345 with Input Filter
(9%)
384 with Input Filter
(4%)
463 with Input Filter
(9%)
520 with Input Filter
(4%)
600 554 800 751
Maximal input
current
with input harmonic
filter
A
499 with Input Filter
(9%)
554 with Input Filter
(4%)
669 with Input Filter
(9%)
751 with Input Filter
(4%)
Duration of
progressive power
walk-in
sec 2 or 10
Maximal output
current
A 750 1000
Note:
= 380V or 415V set changing taps on auxiliary supply transformer.
= With mains at –15% and suggested battery elements the UPS maintains the output rated voltage at rated load but
cannot guarantee float charge to battery; the battery does not discharge.
= EN 62040-3 (3.4.5): UPS , rated load, input rated voltage 400V, no current to battery.
= EN 62040-3 (3.4.6): UPS , rated load or overload, input rated voltage 400V, battery on boost charge with maximal
allowed current.
= Set with jumper on Rectifier Control Board (slow or fast).
