User Manual Liebert Hipulse E Chapter 8 - Operating Instructions
Single or '1+N' UPS System Operator Control and Display Panel
(07/04) Page 8-3
Menu Control switches
Four push button switches ESCape [9], DOWN [10], UP [11], ENTER [12], are located below the LCD display and are
used to navigate a menu-driven UPS operating and control system.
Note 1: In addition to entering the day-to-day operating functions, the menu system is also used to set-up various
UPS operating parameters during commissioning. A system of password protection is therefore used to limit the
control functions accessible to the operator, whilst allowing full access to maintenance personnel. A full description
of the available menus is provided in the appropriate User and Commissioning manuals.
Note 2: From the display Panel Menu it possible to select one of the following languages: English (
1
), Italian (
1
),
French, Spanish and German. The sequence is Default Window
⇒ FUNCTION ⇒ ENTER PASSWORD ⇒ PANEL
SETUP
⇒ LANGUAGE.
Default language is English.
Other languages can be selected as: English (
1
), Italian (
1
), Dutch, Swedish and Norwegian. It requires a replace of
the programmable component.
Note: (
1
) Base languages are English and Italian.
9 ESC Pressing the ESCAPE cancels the most recent actions;
i.e. when selecting options it returns the previous window to the LCD;
when setting parameters, it exits the window without saving the new settings;
10 MENU
∇ The DOWN push-button moves a cursor down the LCD over the options offered on certain
windows, and changes the highlighted parameter values in others.
11 MENU
∆ The UP push-button moves a cursor up the LCD over the options offered on certain windows, and
moves a rectangular cursor to the next digit on the right when changing parameter values in
others;
12 ENTER
Pressing ENTER, when selecting options, displays the next window;
The next window is determined by the option which has been selected in the present window.
When selecting new parameters its saves the new parameters.
13 Warning Indicator — The red LED within the Alarm Silence Switch illuminates when a WARNING alarm is
displayed on the LCD message screen, and is normally accompanied by an audible alarm.
14 Alarm Silence Switch — Pressing the Alarm Silence Switch cancels the audible alarm but leaves the warning
message displayed until the inappropriate condition is rectified.
