3.2.1 Switchboards
Figure 11
One switchboard (1) and part of the fuses and relays are located underneath the driver's seat.
The seat must always be fixed in place with the original screws (2) when driving the machine.
WARNING
If the driver's seat has been opened, always ensure it is secured with the
original mounting screws before driving.
Figure 12
Another switchboard and rest of the fuses and relays are located behind the right cabin door.
► Open the door for easy access (see 4.1 on page 24).
