LM Trac 287 - Maintenance Item Locations

LM 287 User Manual – 30.10.2023
65
Maintenance items
Maintenance intervals according to operating hours
10
50
125
250
500
1000
1500
2000
3000
41
Crankcase Breather Filter Element
(605129049610) and O-ring (42160512904961)
replace
x
x
42
Alternator inspect
x
43
Starting Motor inspect
x
44
Cooling System cleaning
x
45
Engine Mounts inspect
x
46
Handbrake Valve Coil (6031290223) replace
x
47
Thermostat (LMPE145206230) replace
x
48
Water Pump inspect
x
* In normal conditions. In dusty conditions service more often. See 6.10.6, 6.10.7, 6.12.1, 6.12.4 and 6.14.6.
Δ - Wheel fastener tightening torque must be checked daily during first 50 hours.
(O) - Perform maintenance when the hour counter reads 50 hours and thereafter according to normal maintenance
program X.
6.7.2 Maintenance item locations
The reference numbers in the figure also refer to the locations in the maintenance table.
All maintenance items:
Figure 75
